CH-7001SE,19.0V ~ 36V DC,4.7A 36V DC Max

Battery Models Supported

• SE-2201
• SE-2020

Key Features

• Single bay charger
• For the standard battery model SE-2201 and SE-2020
• Optimized charging for smart batteries
• Ultra low leakage current (<100µA)
• Simple operation – Plug and Play
• Meets international medical and industrial safety standards

Charger Architecture

CH-7001SE is a 1st generation, Level-II SBS v1.1 Li-ion smart battery charger. It communicates with battery via SMBus and automatically provides the charging current. The charger is capable of charging 72V to 33.6V smart Li-ion batteries.

Compatible Adapter

For all models:

• 19V 4.7A, 90W, CH-1947-GM13
• 30V 2.5A, 90W, CH-3025-GM13
