Operating Temperature
|
-30°C to +55°C
|
|
Charging Temperature Range
|
-20°C to +55°C
|
|
Storage Temperature Range
|
-30°C to +70°C
|
10.8V 8.55Ah, 92.34Wh SE-2845
10.8V 8.55Ah, 92.34Wh SE-2845
10.8V 8.55Ah, 92.34Wh
Rechargeable Li-ion Battery
This SE-2845 battery is rechargeable lithium-ion, engineered
and designed for use in a world wide tactical environment,
and is manufactured to meet and exceed Indian military
standard JSS-55555 and ISO-9000 methods and procedures.
This battery meets the requirements of JSS 6140-03 : 2013
and MIL-PRF-32052 with reference to MIL-STD-810H and
MIL-STD-461
#SE28450NR29
Part Number
10.8V
Nominal Voltage
12 Months Warranty
Quality Assured
Long Service Life
Technical Support
- Climatic characteristics
- Mechanical Environment
- Protections
- Key Features
- Description
- Information
- Reviews
- MIL-STD-810H & JSS55555
- Free drop
- Shock
- Vibration
- Air transport
Electromagnetic Environment
- MIL-STD-461G
- FCC Part 15B
The battery packs are provided with an internal electronic circuit for electrical protections related to charging, discharging, short-circuit and temperature.
- Over Voltage
- Short Circuit
- Reverse Polarity
- Tested & certified to redundant safety standards
- Smart battery system compliant to SBS v1.1
- ESD protection up to 8kV
- Industry standard 5 pin and Sub D connector
- 5-Segment LED & LCD (SoC) indicator
- UL certified INR-18650 Lithium ion cells
- Ready to fit design
- No extra development cost
- SMBus v1.1 communication support
- UL-94 V-0 rated ABS enclosure
- JEITA charging profile optimization
- SHA-1 cryptosystem to prevent plagiarism
Technical Specification
| Series | SE-2845 |
|---|---|
| Model | SE-2845 |
| Part Number | SE28450NR29 |
| Pack Designation | 3INR19/65-3 |
| Capacity (typ.) | 8.55 Ah |
| Nom. Voltage | 10.8 Volt |
| Max. Voltage | 12.6 Volt |
| Max. Discharge Current (cont.) | 7.0 A |
| Max. Discharge Current (pulse) | 8.5 A for 10 Sec. |
| Replacement to | BT-70492A, BT-70492B, BT-70492C |
| Visual State of Charge | 5 Segment LCD Display |
| Life Cycle | 1000 Cycles at 25°C |
| Communication | SMBus v1.1 Communication |
| Recommended Charge | Constant current at C/5, 1.7 A with 12.6 V limit, end with timer or when current drops below 0.1 A |
| Dimensions (L × W × H) | 146.0 × 63.6 × 52.0 mm ± 1.0 mm |
| Weight | 550 gm ± 50 gm |
| Weight Energy Density | 184 Wh/Kg |
| Mating Connector | Custom Flat Contacts on Bottom |
| Battery Housing | ABS Plastic UL94V-0 |
| Color | Olive Drab / Black |
| Drawing | DRW-1171 |
Additional information
| Volts | 10.8V |
|---|---|
| Power | 8.55Ah |
| Chemistry | Lithium Ion (Li-Ion) |
