| Working Temperature | -20°C ~ +55°C |
| Storage Temperature | -30°C ~ +70°C, 10 ~ 95% RH |
| High Altitude | 4160m : A2, 60kPa, upto -30°C ± 3°C |
| Working Humidity | 20% ~ 90% RH non-condensing |
| Vibration | 5 ~ 500Hz, 4G 2 hrs. each axis |
SE-8020,25.2V 6.4Ah, 161.28Wh
SE-8020,25.2V 6.4Ah, 161.28Wh
25.2V 6.4Ah, 161.28Wh
REF SE80200NR35
The SE80200NR35 is a 25.2V 6.4Ah, 161.28Wh Lithium
ion smart battery comprises of fourteen 3.6V 3.40Ah
INR-18650 cells in a 7-series, 2-parallel array and can
deliver up to 15A of continuous discharge current.
Charger and Accessories
SES offers suitable charger model CH-7301SE & CH-7302SE
for SE-8020 smart battery. CON-802 & CAL-802 as compatible
connector & lead respectively. Please refer accessories &
charger catalogue for more information
SE80200NR35
Part Number
25.2V
Nominal Voltage
12 Months Warranty
Quality Assured
Long Service Life
Technical Support
- Tested & certified to redundant safety standards
- Ready to fit design
- Smart battery system compliant to SBS v1.1
- No extra development cost
- 5-Segment LED State of Charge (SoC) indicator
- SMBus v1.1 communication support
- Industry standard 5 pin and Sub D connector
- UL-94 V-0 rated ABS enclosure
- ESD protection up to 8kV
- JEITA charging profile optimization
- UL certified INR-18650 Lithium ion cells
- SHA-1 cryptosystem to prevent plagiarism
| ISO 9001:2015 certified | Yes |
| ISO 13485:2016 certified: | Yes |
| Material Safety Data Sheet: | Yes |
| CE compliant: | Yes |
| UN 38.3 certified: | Yes |
| BIS 16046:2015 certified | Yes |
| IEC 62133:2012 certified | Yes |
| UL 2054 certified: | No |
| MIL-STD-810E compliant: | Yes |
| MIL-STD-461C compliant: | Yes |
| JSS-55555 compliant: | Yes |
- Over charge voltage
- Over charge current
- Over temperature
- Reverse polarity
- Over discharge current
- Cell under voltage
- Short circuit
- Burst current
Technical Specication
| Part Number | SE80200NR35 |
|---|---|
| Pack Designation | 7INR19/65-2 |
| Chemistry | Lithium Ion |
| Rated Voltage | 25.2 V |
| Rated Capacity | 6400 mAh |
| Nominal Capacity | 6800 mAh |
| Continuous Discharge Current | 15.0 A max. |
| Peak Discharge Current | 20.0 A, < 6 sec. |
| Charging Voltage | 29.4 V |
| Charging Current | 6.0 A max. |
| Charge Indicator | 5 Segment, LED |
| Communication | SMBus v1.1, SBS v1.1 |
| Charge Temperature | -20°C to +55°C |
| Discharge Temperature | -20°C to +55°C |
| Dimensions | 182.0 × 122.6 × 37.0 mm |
| Weight | 940 g |
Additional information
| Volts | 25.2V |
|---|---|
| Power | 6.4Ah |
| Chemistry | Lithium Ion (Li-Ion) |
