Operating Temperature
|
-30°C to +55°C
|
|
Charging Temperature Range
|
-20°C to +55°C
|
|
Storage Temperature Range
|
-30°C to +70°C
|
14.4V 20.7Ah, 298Wh SE-2791
14.4V 20.7Ah, 298Wh SE-2791
14.4V 20.7Ah, 298Wh
Rechargeable Li-ion Battery
SE-2791 is a rechargeable lithium-ion battery it is
engineered and designed for world wide tactical
environment, and is manufactured to meet Indian military
standards JSS-55555 and JSS 6140-03:2013
This battery meets the requirements of MIL-PRF-32383
withrespecttoMIL-STD-810H &MIL-STD-461G.
Benefits
Wide operating temperature range
Durable high impact Plastic case, UL94V-0
High energy density cells
Built in protection circuitry
SoC & SoH via SMBus v1.1
SE27910NR35
Part Number
14.4V
Nominal Voltage
12 Months Warranty
Quality Assured
Long Service Life
Technical Support
- Climatic characteristics
- Mechanical Environment
- Protections
- Key Features
- Description
- Information
- Reviews
- MIL-STD-810H & JSS55555
- Free drop
- Shock
- Vibration
- Air transport
Electromagnetic Environment
- MIL-STD-461G
- FCC Part 15B
The battery packs are provided with an internal electronic circuit for electrical protections related to charging, discharging, short-circuit and temperature.
- Over Voltage
- Short Circuit
- Reverse Polarity
- Tested & certified to redundant safety standards
- Smart battery system compliant to SBS v1.1
- ESD protection up to 8kV
- Industry standard 5 pin and Sub D connector
- 5-Segment LED & LCD (SoC) indicator
- UL certified INR-18650 Lithium ion cells
- Ready to fit design
- No extra development cost
- SMBus v1.1 communication support
- UL-94 V-0 rated ABS enclosure
- JEITA charging profile optimization
- SHA-1 cryptosystem to prevent plagiarism
Technical Specification
| Model | SE-2791 |
|---|---|
| Part Number | SE27910NR35 |
| Pack Designation | 4INR19/65-6 |
| Capacity (typ.) | 20.7 Ah at C/5 rate |
| Nom. Voltage | 14.4 Volt: 12.0 V to 16.8 V |
| Max. Voltage | 16.8 Volt |
| Max. Discharge Current (cont.) | 15.0 A |
| Max. Discharge Current (pulse) | 24.0 A for 20 mSec. |
| Replacement to | MR-2791, BT-5791, BT-70912AK, TLI-9380E1, BA-3791, BA-3791/U |
| Visual state of charge | 5 Segment LCD (SoC) display |
| Life Cycle | 1000 cycles at 25°C |
| Communication | SMBus v1.1, SBS v1.1 |
| Recommended charge | Constant current at C/5, 4.0A with 16.8V limit. End with timer or when current drops below 0.1A. |
| Dimensions (L × W × H) | 187.5 × 71 × 65.5 mm ± 0.5 mm |
| Weight | 1.25 Kg ± 0.10 Kg |
| Weight energy density | 238 Wh/Kg |
| Connector | Floating type 3.05 mm |
| Construction & Layout | DRW-1142-0 |
| Battery Housing | Nylon / ABS UL94V-0 |
| Color | Black / Olive drab / Tan |
Additional information
| Volts | 14.4V |
|---|---|
| Power | 20.7Ah |
| Chemistry | Lithium Ion (Li-Ion) |
